Autocalibrate
 Ifyouchoose“Autocalibrate”andpress theselectedstationwillautomaticallybe
calibrated.Pleasemakesurethatpressureismadeavailabletothesprinklerbeforestarting
thecalibrationprocess.



Warning
Sprinklerstarts!


Press toleavethemenuaftercalibrationhasfinished.

Forcepositiontoleft
Ifyouchoosethisfunctionthesprinklerneedstobebroughtintoparkingpositionmanually.
Note: Itisfeasibletobringallsprinklers,oneafteranother,manuallyintoparking
position(arcsettingtotheleft,sensormaynottouchtheswitchingcams).
Thenpress
foreachstationtoconfirmthecalibrationprocess.


Theblacksquareontheleftofthebarindicatesthatthemanuallyparkedsprinklerisstoredin
thecontroller.
Press toconfirmwhichwillbringyoubacktotheSectorScoutmenu.

Calibrateallstations
ThisfunctionwillautomaticallycalibrateallSectorScoutstationsinascendingorder,asdescribed
in“AutoCalibrate”.
