Automode‐SectorScoutsprinklers

Insteadofastatusbar,menus

 Auto

 Manualstartprogram

 Manualstartsprinkler

willdisplayasensorpositionbarforstationswithSectorScoutsprinklers.

Fordetailedinformationpleaseseenextparagraph„sensorpositionbar“.



Sensorpositionbar

Thesensorpositionbarwillappearduringcalibrationandoperation(seepreviousparagraph)

anddisplaysthefollowingstates:



Field Status Meaning

1 on Sprinklerinparkingpositiononthelefthandside

1 flashing Sprinklerrunsonthelefthandside

2 on Signalfromsensoronthelefthandside

3 flashing Sprinklerrunsinthecenter

3 n/t

n=numberofsectorrunsfinished

t=totalnumberofsectorruns

4 on Signalfromsensorontherighthandside

5 on Sprinklerinparkingpositionontherighthandside

5 flashing Sprinklerrunsontherighthandside

1+5 flashing Sprinklerisnotcalibrated

3 X

Ifthisfieldshowsonlyonedigititimplieshowmanytimesthe

sensortimehasbeenexceeded(seeparagraph„sensortime“).
