6.Maintenance

Protection

Thecontrollerisprotectedbyasensitive
T0,2AH250V
fuse.
Themostcommoncauseofablownfuseisashort‐circuitedcontrolcableofavalve.Ashort
circuitisbrieflyindicatedbyacheckonthescreen.
Thenthedisplayswitchesoffcompletelyandallmessagesdisappear.

ReplaceFuse

8. Unplugthecontrollerfromthemains.
9. Removethefrontcoverbyunscrewingitsscrews.Thefuseislocatedontheright,abovethe
terminalsforthepowersupplycable(seechapter5–Controller)
10. Removethefaultyfusefromtheholder.
11. Installanewfuse.
12. Replacethefrontcover.
13. Plugthepowersupplycableunitintothemains.
14. Checkproperfunctionofthecontroller.

WARNING Thecontrollerisprotectedbya0.2AH(slow)fuse.
Anyattempttobridge(bypass)thefuseortoreplaceitwith
adifferenttypemayresultinseriousinjuriesand/ordamage
totheunit.


IncreaseNumberofStationstobeControlledbytheController

Factorysettingofcontroller(SG49152)=4stations(equals2SectorScoutstations)
Shouldyouneedtoincreasetheexistingnumberofstations,youcandosoinstepsof4stations
uptoamaximumof24stations.
OrdertherequirednumberofadditionaloutputmodulesNo.SB49112fromyourlocalsupplier.
Eachmodulecomprises4stations.

