InstallOutputModules

1. Unplugthecontrollerfromthemains.
2. Removefrontcover.
3. Pressthenewoutputmoduleupwardsintotheterminalboard.
Replacethefixingscrewandconnectthecoilcable.
4. Checkproperfunctionofthesystem.
5. Setstationruntimeoftheirrigationprogramforthenewmodulesasdescribedearlier.

Thecontrollersoftwareautomaticallydetectsthenumberofstationsinstalled.Thisnumber
cannotbeexceededduringprogramming.
ReplaceOutputModule

1. Unplugthecontrollerfromthemains.
2. Removefrontcover.
3. Disconnectthepowersupplycablefromthedamagedexpansionmodule.
4. Unscrewthemodulefixingscrew.
5. Pulltheoutputmoduledownwardsfromtheterminalboard.
6. Pressthenewoutputmoduleupwardsintotheterminal
board.
 Replacefixingscrewandconnectthecoilcable.
7. Checkproperfunctionofthesystem.





Note
Theoutputmodule(seechapter5–TheController)isreplaceable.Ithasbeendesignedtoburn
incaseofanover‐voltageonthefieldsidetoprotectthecontrollermotherboardfromdamage.
Chapter7–Troubleshootingprovidesguidanceforanalysingvariousfaultsofoutputmodules.


