PHYSICAL SETUP: SIDE CONNECTORS
CBL-AUD-0002 22-Pin to U-328 PTT/EUD Connects to a headset via a U-328 connector.
CBL-AUD-0007 22-Pin to Audio and USB
2.0 Type A Female
PTT/EUD Connects USB accessories via a standard USB A
port and an audio accessory via a U-328 connec-
tor
CBL-AUD-2009 22-Pin to Audio and 6-Pin
Push Pull Android™ USB
PTT/EUD Connects an Android™ EUD or Screen and an
audio accessory via a U-328 connector
What Can I Do Now?
✓
▶ Identify which cable you need for your configuration
▶ Identify which side connector your cables attach to
▶ Connect a cable to a side connector
Refer to the MPU5 Product Catalog for more information on MPU5 cables. If you still have ques-
tions, contact Persistent Systems.
