13
APPENDICES
Classifications Specifications
Frequency Range Band-III : 174
MHz~240MHz
Power source +3.0V +/-20%
Battery 2AA size alkaline cells
Adaptor 3V / 500mA (2.8
Ø)
Audio Output Power 10mW @ 16Ω
Audio Frequency Range 20Hz-20KHz˚
Dimension (W×H×D) 84×60×24 mm
Operating Temperature -5˚C ~ +35˚C
Storage temperature -40˚C ~ +80˚C
Appendix 3 Specifications
Information in this document is subject to change without notice.
