Peter electronic BR Series - 10 Technical Data; Ambient Conditions

10 BR 230/400-10...400
10. Technical data
10.1 Ambient conditions
Type designation
BR ....
230-10
400-10
230-20
400-20
230-40
400-40
230-60
400-60
230-100
400-100
230-200
400-200
230-400
400-400
Nominal voltage
according to DIN EN
50160 (IEC 38)
BR230 ... 220/240V ±10% 50/60Hz other voltages
BR400 ... 380/415V ±10% 50/60Hz upon request
Power draw of the
electronics
6 VA
Recommended for
rated motor currents
up to
5A 10A 20A 30A 50A 100A 200A
Rated device current 10A 20A 40A 60A 100A 200A 400A
c.d.f. at max. braking
current
20% 20% 15% 15% 15% 15% 15%
I²t-value of power sem-
iconductors (A²s)
40 680 8000 8000 8000 80000 320000
Braking voltage 0 ... 130VDC at 220/240V
0 ... 220VDC at 380/415V
Braking time 2 ... 14s
(other times upon request)
Contact rating relay contact for motor contactor = 6A/250VAC; 6A/30VDC
- contact for braking contactor
= 6A/250VAC; 6A/30VDC
Delay time for reduc-
tion of residual e.m.f.
250ms 250ms 600ms 600ms 1500ms 1500ms 1500ms
max. Cross-sectional
area / connect. cable
2,5mm² 2,5mm² 16mm² 16mm² 35mm² 35mm² Screw
M8
Weight 0,5kg 0,55kg 2,4kg 2,4kg 2,55kg 3,55kg 7,6kg
Storage temperature -25 ... 75°C
Operating temperature 0 ... 45°C
Protection class IP 20
Environment Overvoltage category III, pollution degree 2
