Peterbilt 337 2017 - WARNING SYMBOLS

WARNINGSYMBOLS
WARNINGSYMBOLS
StandardWarningLights
andAudibleAlarm
Thewarninglightsandaudiblealarm
mayindicateasystemmalfunction.
Checkthelightsfrequently,and
respondproperlyassoonasyousee
onegoon.Theselightscouldsave
youfromaseriousaccident.
WARNING!
Donotignoreawarninglightor
audbilealarm.Thesesignalstell
yousomethingiswrongwithyour
vehicle.Itcouldbeafailurein
animportantsystem,suchasthe
brakes,whichcouldleadtoanacci-
dent.Havetheappropriatesystem
checkedimmediately.
1.DriverInformationDisplay
2.StatusIndicator
3.LowerLightBar
Warninglightsandindicatorsymbols
willbeshowninbothareas1and2.
Area3isdedicatedtotheturnand
highbeamindicatorsymbols.
1.DriverInformationDisplay:The
displaycanshowuptosixwarning
lights.Warningsdonothavexed
positionsandaredisplayedinorder
ofcriticality.Themostcriticalwarning
willbedisplayedonthetoprowand
totheleft.Ifmorethansixwarnings
areactive,themenucontrolswitch
(MCS)canbeusedtoscrollthrough
theadditionalwarnings.
2.StatusIndicator:Additionallights
andindicatorsymbolsaredisplayedin
theStatusIndicator.Theyarelimited
to:
•ParkBrake
•TransmissionGear(Automatic
transmissionsonly)
•Warnings
•CruiseControl-active
•Clockalarmbell
RefertoWarningLight/Indicator
Symbolsonpage3-11forinformation
oneachsymbol.
(03/17)Y53-6060-1C13-9
