Peterbilt 520 - Page 170

Every 60,000 mi / 96,000 km / 6 Months
18
Power Steering - Reservoir (OFF HIGHWAY)
•
Drain, replace the filter, and refill. (Refer to Power Steering Fluid on page 237 for maintenance instructions.)
Power Steering - Steering Gear
• Check the lash of the sector shaft: adjust as required. (Refer to Steering System on page 236 for maintenance instructions.)
• Grease the trunnion bearing (EP NLGI #2 lithium-based, moly-filled, HD grease.) (Refer to Steering System on page 236 for
maintenance instructions.)
• Grease the input shaft seal (EP NLGI #2 lithium-based, moly-filled, HD grease.) (Refer to Steering System on page 236 for
maintenance instructions.)
Power Steering - Hoses and Tubes
• Check for leaks and chafing. (Refer to Steering System on page 236 for maintenance instructions.)
Steering Components - Drag link Tube Clamp and Ball Socket
• Check the torque: tighten to specified torque value as required. (Refer to Steering System on page 236 for maintenance
instructions.)
Steering Components - Pitman Arm Clamp Bolt and Nut
• Check the torque: tighten to specified torque value as required. (Refer to Steering System on page 236 for maintenance
instructions.)
Steering Components - Steering Intermediate Shaft
• Check the torque on the pinch bolt and nut. (Refer to Steering Shaft Bolt Torque Specifications on page 238 for maintenance
instructions.)
18
Ensure that all maintenance intervals leading up to this point are repeated during this interval prior to the completion of
those listed here.
MAINTENANCE - Every 60,000 mi / 96,000 km / 6 Months
170 Y53-6096-1C1 (09/20)
5
