Where to add Coolant?
Coolant may be added via the fill cap on
the tank.
WARNING
Removing the fill cap on a hot engine
can
cause scalding coolant to spray
out and burn you badly. If the engine
has been in operation within the previ-
ous 30 minutes, be very careful in re-
moving the fill cap. Protect face,
hands, and arms against escaping flu-
id and steam by covering the cap with
a large, thick rag. DO NOT try to re-
move it until the surge tank cools down
or
if you see any steam or coolant es-
caping. Always remove the cap very
slowly and carefully. Be ready to back
off if any steam or coolant begins to
escape. Failure to comply may result
in death, personal injury, equipment or
property damage.
1. Fill cap
2.
Sight glass
Inspect Coolant Level
T
op off coolant when the level in the surge
tank is below the sight glass on the side of
the tank. Coolant is added through the
pressure cap fill neck.
1. Fill cap
2.
Sight glass
How to Add Coolant to the Cooling
System
Add coolant through the surge tank fill cap.
Do not remove the pressure cap to fill the
cooling system.
MAINTENANCE - Cooling System Maintenance
Y53-6096-1C1 (09/20) 201
