Peterbilt 520 - Page 49

Left Hand Drive (Shown with optional dual drive configuration)
1
2
3
4
5
6
7
8
9
11
12
10
1. Information Display
2.
Cup Holder
3. Automatic Transmission
Gear Selector
4. Primary Ignition Switch
5. Window Switches
6. Mirror Control
7. Electronic Switches for
Controls from Either
Driving Position
8. 12V Charge Port
9. Left Hand Side Electronic
Switches
10. Arm Rest/Storage Box
11. OBD Port
12. Secondary Ignition
Switch
CONTROLS - Instrument Cluster
Y53-6096-1C1 (09/20) 49
