Comparing Hub Piloted and Ball
Seat Parts
WARNING
Do not mismatch wheel components.
Equipment that does not exactly match
original specifications or that is mis-
matched
could cause the wheels to
break and separate from the vehicle.
The resulting accident could be very
serious. Each mounting system is en-
gineered for use only with its correct
mating part. Be sure properly matched
components are used for each type of
mounting. Failure to comply may result
in
property damage, personal injury, or
death.
The following comparison (Comparing
Hub-piloted and Ball-seat Wheels on page
272), shows the dif
ference between parts
used in hub pilot mount and ball seat
mount applications.
Comparing Hub-piloted and Ball-seat Wheels
HUB-PILOTED MOUNT
BALLSEAT MOUNT
Hub, Drum, and Stud Assembly
MAINTENANCE - Wheels
272 Y53-6113-1A1 (11/20)
