Wheel and Nut Configuration Stud Size
Torque for Inner and Outer Cap Nuts and Rim Clamp Nuts
lb-ft N•m
Heavy-Duty Steel Disc-Type
Wheel; Double Cap Nut
Mounting; 1-3/16 Radius Ball
Seat:
15/16-12 750-900 1,020-1,220
1-1/8-16 750-900 1,020-1,220
1-15/16-12 750-900 1,020-1,220
Hub-Piloted Disc-Type Wheel
w/T
wo Piece Flanged Cap Nuts:
Steel or Aluminum Wheel
PHP-10; Budd Uni-Mount-10;
WDH-8
M22-1.5 450-500 610-680
Stud Backnuts (when used) 3/4-16 175-200 240-270
1-14 175-300 240-410
Cast Spoke Wheel Assembly
Rim Clamp Nut Torque
1/2 in. Dia. 80-90 110-120
5/8 in. Dia. 160-185 220-250
3/4 in. Dia. 225-245 305-335
Lubrication Specification Chart
NOTE
The responsibility for meeting these
specifications,
the quality of the prod-
uct, and its performance in service
rests with the lubricant supplier
.
*Consult manufacturer or lubricant supplier
for special details.
MAINTENANCE - Specification Reference Charts
276 Y53-6113-1A1 (11/20)
