1. Direction indicators (P 21 W).
2. Reversing lights (P 21 W),
left-hand side.
Fog lamp (P 21 W),
right-hand side.
3. Brake lights (P 21 W).
4. Side lights (x 2) (R 5 W).
 Using a 10 mm box spanner, un-
screw the 2 fixing nuts 1.
 Release the lamp unit by pushing
it outwards.
 Squeeze the two tabs 2 to release
the bulb holder.
 Change the faulty bulb.
 When refitting, ensure that the
lamp unit seal has been put back
in place correctly.
These 6 bulbs are changed from in-
side the boot:

Move aside the boot trim to ac-
cess the bulb holder,

Press the two tabs and remove
the bulb holder,

Change the faulty bulb.
When refitting, take care to pass the
trim under the seal.
Rear lights (saloon)
Third brake light (saloon)
(4 W 5 W bulbs)
