9
PRACTICAL INFORMATION
Access to the fuses
) Open the glove box,
) Push the two opening guides A in-
wards to pass the fi rst notch,
) Remove the retaining tab B pulling
it outwards,
) Support the cover and tilt it down-
wards,
) Change the fuse (refer to the cor-
responding paragraph).
* The maxi-fuses provide additional protection for the electrical systems. All work on the maxi-fuses must be carried
out by a PEUGEOT dealer or a qualifi ed workshop.
Fuse N° Rating Functions
17 10 A 4 wheel drive control unit.
18 7.5 A
Reversing lamps, parking sensors control unit,
reversing camera, airbag control unit.
19 15 A Accessory socket.
20* 30 A Electric window controls.
21 * 30 A Rear screen demisting.
22 7.5 A Heated door mirrors.
23 - Not used.
24 25 A
Driver’s electric seat, footwell lighting, rear bench
seat release.
25 30 A Heated seats.
