ELECTRIC COMPONENTS
17
Reproduction or translation, even partial, is forbidden without the written consent of Peugeot Motocycles
• Oil pump (3).
• The temperature sensor (4).
Refit a sensor quickly to prevent loss of coolant.
Removal of the high tension coil.
- Remove the footboard and the left tunnel (see
procedure 3)
- Disconnect the coil (1) and the spark plug
lead.
- Remove the high tension coil.
4
3
1
