Pfaff 3371-1 series Adjustment Manual

Adjustment
14 - 4
Fine adjustment
● Switch on the machine.
● In the input mode, select parameter "608", see Chapter 11.03 Parameter input in the
instruction manual.
● If necessary, enter the access code, see Chapter 11.04.01 Entering the access code in
the instruction manual.
● With the corresponding plus/minus key move the work clamp drive unit in accordance
with requirement 1, also see Chapter 11.03 Parameter input.
● Switch off the machine.
● Remove adjustment gauge 1.
● Fit the lower feed plate and work clamp holder.
If, during the fine adjustment, the setting is ± 5 increments above or below the
value in X- and Y-direction, the setting should be checked again in accordance
with requirement 2.
