8
Adjustment
1
3
4
1
.05.02
Preliminary adjustment of the needle height
Requirement
With the needle bar at
TDC (pin in hole
1
) the needle point must be positioned
11
mm
abov
e the needle plate, or in the case of the H-model
12
.
5
mm
.
●
Bring the needle bar
1
to
TDC.
●
Adjust needle bar
1
(scre
w
2
) according to the
requirement
.
Fig. 1 - 02
1
2
1
1 or 12,5 mm
7
9
