Adjustment
38
Fig. 1 - 32
● Adjust nut 1 (nut 2) in accordance with the requirement and lock it with nut 2.
1.05.32 Knee lever play
Requirement
When lightly pressing the knee lever there should be a noticeable play between nut 1 and
fork 3.
2
1
3
