2:11
A
B
Technical section
Inserting the bobbin
Insert the full bobbin (with the Pfaff logo facing towards
the bobbin case) in the bobbin case. When doing so, pull the
thread through slot A, then under tension spring B until it
rests in the opening (see arrow).
Check:
When you look at the bobbin and pull the thread, the bobbin must
turn clockwise
Inserting the bobbin case
Lift latch E and push the bobbin case fully onto pin C of
the sewing hook. Opening D of the bobbin case must face
upwards.
Check:
Pull the bobbin thread sharply. The bobbin case must not fall out
of the hook.
