7:2
Maintenance
Changing the needle plate
Switch off the main switch.
Removal
• Raise the presser foot. Position the needle plate changer
(lamp changer) as shown, and press the needle plate
up on the right, then on the left. It can now be easily
removed.
Replacing
• Place the needle plate against the rear edge of the cut-
out then press down at the front until you hear it snap
in place. Before you start sewing, check that the needle
plate is lying Á at.
Tip: Lower the feed dog to make removing the needle plate easier.
Cleaning
Switch off the main switch.
• Remove the needle plate and lower the feed dog. Clean
the feed dog and hook area with the brush.
• Clean the sewing machine every 10 - 15 hours of
operation.
Cleaning the display
Wipe the display with a soft, lint-free dry cloth. DO NOT
use aggressive cleansers or solvents!
