5
30
31
35 36
37
38
39 40
41
42 43
34
33
32
21
26 27 28 29
22 23 24 25
Top parts
21. Presser foot pressure dial
22. Thread guides
23. Spool caps
24. Hole for auxiliary spool pin
25. Bobbin winder lever and
bobbin spindle
26. Take-up lever
27. Thread tension discs
28. Bobbin winder tension disc
29. Thread tension dial
Rear side
30. Main switch, connectors for power
cord and foot control
31. Handle
32. Presser foot lift
33. IDT™ system
34. Slide for lowering the feed dogs
Accessories
Included accessories
35. Bobbins (5) (#416475801)
36. Felt pad
37. Screwdriver for needle plate
38. Multi-purpose tool
39. Spool cap, large (2)
40. Spool cap, small
41. Seam ripper & brush (as one)
42. Edge guide
43. Auxiliary spool pin
Included accessories not in picture
• Foot control
• Power cord
• Needles
• Hard cover
