GB 02863 - Edition 07 - Oct 13
1/2
MANUAL P/N : 112241
E
DITION : 07 - November 2013
General contents
Operating instructions - A3P Series
English original version
Chapter A INTRODUCTION
A 10 Operating principle
A 20 Description
A 30 Monitoring system
A 40 Technical characteristics
A 50 Accessories
A 60 Options
Chapter B START UP
B 00 Safety instructions
B 01 A3P Series - Hook-up requirements
B 10 Unpacking / Handling / Storage
B 20 Positioning the pump in the pumping installation
B 30 Connection to the cooling circuit
B 40 Inert gas purge connection (N
2
connection)
B 50 Electrical connection
B 51 Checking the direction of rotation at initial pump start-up (for A603P
pump only)
B 60 Connection to the pumping circuit
B 70 Remote control plug connection
B 80 Safety plug connection
B 90 User plug connection
B 100 EMO plug connection (on A603P / A1003P pump models)
B 110 RS 232 or RS 485 link wiring
B 120 Removable handle (accessory) installation
Chapter C OPERATION
C 00 Safety recommendations for harsh processes
C 10 Operating modes
C 20 Monitoring system parameters
C 25 Safety management
C 40 Operating mode with hand held display module (accessory)
C 41 Start up of the monitoring system
C 42 Monitoring system function table
C 43 Starting mode definition «Hand held display module»
C 44 Saving and loading of pump configuration
C 45 Monitoring system setting for transport
C 70 Use of the inlet isolation valve (accessory)
C 90 Use of the serial link
Chapter D TROUBLESHOOTING
D 00 Safety instruction related to maintenance
D 10 First level of maintenance
D 20 Fault message number table
D 30 Diagnosis and troubleshooting
Chapter E MAINTENANCE INSTRUCTIONS
E 10 Standard repair exchange
E 11 Preliminary precautions
E 12 Draining of the water cooling circuit
E 14 Disconnecting the pump from the installation
E 15 Shipping procedure
E 20 Increase the maintenence parameters
adixen Vacuum Products - Operating instructions - A3P Series
