1 About this manual
IMPORTANT
Read carefully before use.
Keep the manual for future consultation.
1.1 Validity
These operating instructions are a customer document of Pfeiffer Vacuum. The operating instructions
describe the functions of the named product and provide the most important information for the safe use
of the device. The description is written in accordance with the valid directives. The information in these
operating instructions refers to the product's current development status. The document shall remain
valid provided that the customer does not make any changes to the product.
1.1.1 Applicable documents
Document Part number
OBCV4 Electronic Drive Unit Operating instructions 129285
ATH 1300 - 1600 M/MT Operating instructions 105677
ATH 1603 M - ATH 2303 M/MB Operating instructions 115101
ATH 2300 M/MT Operating instructions 108895
ATH 2804/3204 M/MT Operating instructions 121608
ATP 1603 M Operating instructions 127646
ATP 2300 M Operating instructions 112419
1.1.2 Variants
This operating instruction applies to the products with the following part numbers:
Part number Description
129353 OBC Electronic drive unit V4, equipped with Profinet™ control interface
- OBC Electronic drive unit V5, equipped with Profinet™ control interface
These products are used in conjunction with magnetically levitated turbomolecular pump models operat-
ed with :
●
electronic drive unit (OBCV4) : ATH 1300 M (MZxxxxxx), ATH 1600 M (PZxxxxxx), ATH 1603 M
(YZxxxxxx), ATH 2300 M (QZxxxxxx), ATH 2303 M (TMBBGxxxxxxx), ATP 1603 M
(TMDBGxxxxxxx), ATP 2300 M (TZxxxxxx).
●
electronic drive unit (OBCV5) : ATH 2804/3204 M (TMAAGxxxxxxx)
1.2 Target group
These operating instructions are aimed at all persons performing the following activities on the product:
●
Transportation
●
Setup (Installation)
●
Usage and operation
●
Decommissioning
●
Maintenance and cleaning
●
Storage or disposal
The work described in this document is only permitted to be performed by persons with the appropriate
technical qualifications (expert personnel) or who have received the relevant training from Pfeiffer Vac-
uum.
