3)7*67$1'$5' 86$
3URFHGXUHVDWHQGRIZRU NDQGFOHDQLQJ
BBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBB
BBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBB
________________________________________________________________________________________
:$51,1*
Before dismantling the rotor/stator pump, it is essential to ensure that the pump and
the hoses are depressurized. Observe the reading on the mortar pressure gauge.
- When work finishes, switch off the material supply (star wheel) (turn star
wheel switch (1) to the position "0"!)
- empty mixing tube
- press the button (2) "OFF"
Switch off the compressor and open the tap on the spray gun.
- Plug out 7 pole plug at mixing tube
- Tip up the motor by releasing the tilt flange fast release clamp.
- Take out the mixing shaft and clean it. Clean the mixing zone with a trowel.
