Figure 3 - User Interface Menu Tree (factory defaults shown in bold)
Attribute Value Description
Alarm Volume High Beeper volume high
Silence Timeout 30 Minutes before resumption of audible alarm
Calib Frequency Hour Multiple times daily
Calib Interval 6 Every 6 hours
Calib Time 6 6 AM (will only take effect if Freq is set to Day)
CT Range 0 Load Monitoring disabled
Pri Brkr Amps 80 80% of CT Range setting
Load Alarm Limit 80 Alarm at 80% of primary breaker amps rating
Temp Monitor Off Transformer temperature monitoring disabled
Hazard Current Range 5mA Full-scale hazard current
Table 2 - Default Settings
Main Menu
View Cfgr
Alarms
Events
Hour
Minute
Month
Day
Year
Info
Exit
LIM Alarm
Volume
High Low Mute
Silence
Timeout
Minutes: 5, 10, 30, 60, 120
Auto-Cal
Frequency Basis
Daily By Hour
Auto-Cal Time Time of day if Daily, interval if By Hour (6)
Optional - Load Current
Meter Range
Amps: Inactive, 10, 20, 50, 100, 150, 200
Primary Ckt Brkr Amps
(Full Load Amps)
From 1 to Meter Range (80% of Meter Range)
Load Alarm Limit
(% of FLA)
From 5 to 100% of FLA (80%)
Shown only if Load Current Meter is set other than Inactive
Optional - Transformer
Temperature Monitor
Off On
Hazard Current Range
5mA 2mA
Language
English Español
