Page 6
© 2014 PG LifeLink, Inc. - All rights reserved
PG L
IFELINK Mark V Line Isolation Monitor Instruction Manual Rev. 2.0
hardware are provided. Inform factory sales representative or application engineer
of existing installation details when ordering.
Each LIM is supplied with a wiring harness complete with 15-pin header connector
(J-2). Ensure that power is disconnected prior to installation or any contact with
wiring harness or connectors. Header is polarized to prevent reverse connection.
Use caution when connecting or disconnecting header. Carefully align with pins
located on underside of LIM. Remove by securely holding header and pulling
straight down to avoid bending pins. Do not pull on wires as they may be
dislodged from header and adversely affect LIM operation.
Refer to wiring diagram below (Figure 2) for proper connection. Wiring connection
details are dependent on the various options installed, including RS-485 to Ethernet
converter for LIM-C
ONNECT
TM
, transformer load monitoring transducer, transformer
temperature alarm, and external remotes.
(Yellow)
(Yellow)
Isolated Power
Line & Room
Reference Gnd
Ref Gnd
Common
Remote
Annunciators &
Communication
Alarm
Relay
Contacts
Optional
Transformer
Monitors
(White)
(Pink)
(Blue)
(Blue)
TB-Remote
J2
(Inside IPS Panel)
Reference
Ground Bus
Bus Bars
Isolated Power
L1
L2
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
7
6
5
4
3
2
Ref Gnd
RS-485 -
RS-485 +
Gnd
+5 VDC
Alarm
N.O.
Temp
Common
Load
(Red)
(Black)
(Violet)
(Gray)
(Green)
(Green)
(Orange)
(Brown)
(Yellow)
(Blue)
(White)
(Pink)
1
11
10
9
8
& Header Connector
Xfmr
Over-Temp
Sensor
(Optional)
LIM-Connect
Software
Ethernet
Converter
(Optional)
TXD A
L1
L2
J1
Accessory
Pwr Supply
15 VDC
(Optional)
J2
-
+
TXD B
RXD A
RXD B
SGND
GND
15 VDC
Xfmr
Prim.
(H1)
Xfmr Load
Tranducer
4-20 mA
(Optional)
+
-
CAT5
To Facility
Equipment
Subnet
(by Others)
#18 AWG, 3-Conductor
Un-Shielded, Max. 300 Ft.
Typical (by Others)
#16 AWG, 4-Conductor
Un-Shielded, Max. 150 Ft.
Typical (by Others)
To BMS
for Alarm
Indication
(Optional)
(White)
(Red)
L1 L2
Notes:
1. Remote annunciators are ordered separately. A maximum of (3ea.)
remotes may be connected in parallel to a single LIM using up to the
maximum conductor length indicated. Consult factory for
applications requiring longer connection lengths.
2. Only connect LIM to PG LifeLink remote annunciator models and
accessories listed. Connection to unapproved equipment may void
warranty and cause severe equipment damage.
3. Alarm Relay contacts are rated up to 1A @ 30 VDC. Controls
contractor is responsible for supplying suitable power source and
control wiring to BMS interface.
(Red)
(Black)
(Violet)
(Gray)
Gnd
Alarm
RS-485 +
RS-485 -
Gnd
+5 VDC
+5 VDC
3
4
DRA-VS
Full Feature
Remote
Annunciator
(Optional)
DRA-1
Basic
Remote
Annunciator
(Optional)
2
1
3
2
1
J1
TB1
(Alarm)
(Norm)
N.C.
Isolated Power System
Enclosure
LIM Wiring Harness
(Bottom of LIM)
Figure 2 - Wiring Diagram
