4.3 HANDLE SWITCH
1. Hi/Lo Beam Switch
Turn to“≣D＂for far distance lightening,“///D＂for near distance.
⑤
④
2. Turn Signal Button
Left/Right turn:Turn the button to the left / right side. The button will returen to central
position automatically after pushing the button to “OFF＂the signal.
3. Horn Button
Push the horn button, the sound will be heard.
4. Engine Off Switch
Engine will be forced to stop while switched to “OFF＂position. Engine will be allowed
to restart if switched to“RUN＂position.
5. Start Button
Pull the break lever, and push the start button simultaneously, then the engine will be started.
6. Light Switch
Turn it to the first shift, the fog light will be “ON＂. To the second shift, the head lamp &
rear be“ON＂.
7. Overtake Lamp
The lamp will blink after pushing the button.
