YOU WILL NEED THE FOLLOWING TOOLS TO ASSEMBLE YOUR PGS GAS GRILL:
1 - Mallet or Hammer 1 - Med. Phillips Head Screw Driver
2 - 6" Adjustable Wrenches 1 - Small Roll of Teflon Tape (Natural Gas Only)
50% Soap and Water Solution 1 - Spray bottle or brush
Having these additional tools on hand will make assembly easier:
1 - 1/2" Socket and Drive 1 - 7/16" Socket and Drive
PGS NUTS, BOLTS AND FASTENERS FOR IDENTIFICATION
(PLEASE NOTE: NOT ALL OPTIONS REQUIRE QTY. BELOW)
REF # DESCRIPTION QTY. PART # USED FOR:
1 5/16 X 3/4" BOLT 6 101030 Base to Pedestal
2 5/16” WASHER 6 101260 Base to Pedestal
3 5/16” LOCK WASHER 6 101280 Base to Pedestal
4 5/16” NUT 6 101130 Base to Pedestal
5 1/4 X 20 X 1-1/4" BOLT 4 101010 Head to Pedestal Assembly
6 CAGE NUT 4 101220 Head to Pedestal Assembly
7 1/4" WASHER 4 101240 Head to Pedestal Assembly
8 1/4" LOCK WASHER 4 101270 Head to Pedestal Assembly
9 3/8 X 16 X 1" BOLT 2 101035 Side Handle Bolt
10 3/8” STAR WASHER 2 101200 Side Handle Washer
11 HINGE PIN 2 101050 Upper Casting to Lower Casting
12 COTTER PIN 2 101040 Through Hinge Pin to Secure Top Casting
13 8 x1/2” SHEET METAL SCREW 2 101150 Collar Box to Pedestal / Control Panel
14 TINNERMAN CLIP 2 101210 Collar Box to Pedestal / Control Panel*
*NOTE: 2 ADDITIONAL SCREWS/TINNERMAN CLIPS ARE PRE-ATTACHED TO THE BOTTOM OF THE CONTROL PANEL
15 FEEDLINE MOUNTING CLIP 1 100340 To Secure Feedline (Pre-mounted on Feedline)
16 10-32 S.S. MACHINE SCREW 3 101160 1 for Feedline Mounting Clip, 2 for Tank Strap
17 1/4 X 20 X 3/4" BOLT 4 101020 Side Shelf Assembly
18 1/4" WASHER 4 101240 Side Shelf Assembly
19 1/4" LOCK WASHER 4 101270 Side Shelf Assembly
20 1/4" NUT 4 101140 Side Shelf Assembly
21 AXLE CAP 2 100160 Wheel Hubs
22 1/4 X 20 X 3/4" BOLT 3 101015 Permanent Post Head to Post Bolt (if purchased 48”
Permanent Post)
23 1/4 X 20 NUT w/LOCK WASHER 3 101100 Nut for above (if purchased 48” Permanent Post)
