4 5
TABLE OF CONTENTS
1. SPECIFICATIONS ................................................................................................................................................................................................................. 5
2. EXPLODED VIEW ................................................................................................................................................................................................................ 6
3. ACCESSORIES & BRACKETS ............................................................................................................................................................................................. 8
4. I/O PORTS ............................................................................................................................................................................................................................. 9
5. CONNECTIONS ................................................................................................................................................................................................................... 10
6. PANEL REMOVAL ................................................................................................................................................................................................................ 11
7. MOTHERBOARD INSTALLATION ................................................................................................................................................................................... 13
8. POWER SUPPLY INSTALLATION .................................................................................................................................................................................... 14
9. FILTERS REMOVAL ............................................................................................................................................................................................................. 15
10. FANS COMPATIBILITY ....................................................................................................................................................................................................... 16
11. RADIATOR BRACKET INSTALLATION ........................................................................................................................................................................... 17
12. HARD DRIVE CAGE ............................................................................................................................................................................................................ 19
13. DROP-N-LOCK SSD BRACKET ........................................................................................................................................................................................ 20
14. MULTIFUNCTIONAL MID PLATE ................................................................................................................................................................................... 21
15. WATERCOOLING INSTALLATION .................................................................................................................................................................................... 22
16. UPGRADE OPTIONS ........................................................................................................................................................................................................... 24
17. SERVICES AND SUPPORT ................................................................................................................................................................................................ 25
1. SPECIFICATIONS
PH-F140 Premium Fan (1x included)
Speed (rpm) 500-1600 ±250 rpm
Max Airow 68.1 CFM
Static Pressure 1.62 mm H2O
Acoustical Noise 17-25.3 dB (A)
CLEARANCE
Graphic card 330 mm (13 in)
CPU cooler 200 mm (7.9 in)
Cable Management 28 mm (1.1 in)
Motherboard - Radiator 120 mm form factor: 70 mm (2.76 in)
140 mm form factor: 50 (1.97 in)
Warranty 5 Years
CASE SPECIFICATIONS
Dimension 230 mm x 375 mm x 395 mm (W x H x D)
Form Factor Mini ITX Tower
Material(s) Steel Plates, Plastics, Steel chassis
Motherboard support Mini ITX
Front I/O 2x USB 3.0, Mic, Headphone, RGB switch
Side window Yes, Tempered glass
EXPANSION & DRIVE BAYS
Expansion slots 2
Internal 3.5” 2 (1x extra upgrade slot)
Internal 2.5” 1 (1x extra upgrade slot)
COOLING 120 mm 140 mm 200mm
Front 2x 2x 1x
Top 2x 2x -
Rear 1x (1included) 1x -
LIQUID COOLING 120 mm radiator 140 mm radiator
Front Up to 240
Top Up to 240 Up to 280
Rear 120 140
