Phantom 60 Series - Electrical Specifications

PHANTOM 60 SERIES BALLAST ELECTRICAL SPECIFICATIONS
Model Watts
Main
Voltage
Operating
Voltage
Range
Max
Input
Power
Output Power Settings
Power
Factor
Ignitor
Voltage
THD CF ta tc
PHB6015 1000W 208–240V 185–265V 1236W 600W-660W-750W-825W-
1000W-1150W
> 0.97 3–5 kV < 8% 1.414–1.6 40°C/104°F 80°C/176°F
PHB6024 1000W 277–400V 249-440V 1236W 600W-660W-750W-825W-
1000W-1150W
> 0.97 3–5 kV < 8% 1.414–1.6 40°C/104°F 80°C/176°F
PHB6030 1000W 480V 432-528V 1226W 600W-660W-750W-825W-
1000W-1150W
> 0.97 3–5 kV < 8% 1.414–1.6 40°C/104°F 80°C/176°F
ELECTRICAL SPECIFICATIONS
Model
BALLAST INPUT AMPERAGE REFERENCE
PHB6015
Irated 208/240V 1150W 208/240V 1000W 208/240V
825W 208/240V
750W 208/240V 660W 208/240V 600W 208/240V
6.1A/5.3A 6.1A/5.3A 5.4A/4.7A 4.5A/3.9A 4.1A/3.6A 3.7A/3.2A 3.3A/2.9A
PHB6024
Irated 277/400V 1150W 277/400V 1000W 277/400V 825W 277/400V 750W 277/400V 660W 277/400V 600W 277/400V
4.8A/3.3A 4.8A/3.3A 4.1A/2.8A 3.4A/2.4A 3.1A/2.2A 2.8A/2.0A 2.5A/1.8A
PHB6030
Irated 480V 1150W 480V 1000W 480V 825W 480V 750W 480V 660W 480V 600W 480V
2.8A 2.8A 2.4A 2.0A 1.8A 1.6A 1.5A
• Microprocessor Control
• LED Status Indicator
• Open Circuit Protection
• Open Circuit Indicator
• Short Circuit Protection
• Short Circuit Indicator
• Overtemperature Protection
• Overtemperature Indicator
• End-of-Lamp-Life Sensor
• End-of-Lamp-Life Indicator
• Over/Undervoltage Protection
• Over/Undervoltage Indicator
• Patented Ignition Control
• RJ12 Port to Integrate with PX Lighting
Controller
• Auto-restrike Protection
• Internal EMI Suppression
• 18/3 AWG Power Cord
• Vent Plug
PHANTOM 60 SERIES BALLAST FEATURES
