Phantom Ultrahigh-speed Camera Manual
v2512 v2012 v1612 v1212
Max. Speed
25,600 fps at
full resolution
1280 x 800;
1,000,000 fps at
reduced resolution
of 128 x 32
w/FAST option
(677,000 w/o)
22,0000 fps at
full resolution
1280 x 800;
1,000,000 fps at
reduced resolution
of 128 x 32
w/FAST option
(666,000 w/o)
16,000 fps at
full resolution
1280 x 800;
1,000,000 fps at
reduced resolution
of 128 x 16
w/FAST option
(647,000 w/o)
12,000 fps at
full resolution
1280 x 800;
820,000 fps at
reduced resolution
of 128 x 16
w/FAST option
(571,000 w/o)
Min. Speed
100 fps
Pixel
28 μm size, 12-bit depth
Sensitivity
Monochrome: 32,000D (Daylight)*; 100,000T (Tungsten)
Color: 6,400D*; 10,000T*
CAR
128 x 16 (Continuous Adjustable Resolution)
Throughput /
Speed
25 Gpx/s /
25,000 fps
20 Gpx/s /
20,000 fps
16 Gpx/s /
16,000 fps
12 Gpx/s /
12,000 fps
1 Gpx/s throughput Direct Record to Phantom CineMag IV
Exposure
1 μs minimum
standard;
280 ns min w /
FAST option
1 μs minimum
standard;
305 ns min w /
FAST option
1 μs minimum
standard;
500 ns min w /
FAST option
1 μs minimum
standard;
500 ns min w /
FAST option
Exposure
in PIV
375 ns 425 ns 400 ns 550 ns
Memory
72GB, 144GB, 288GB high speed internal RAM
CineMag IV non-volatile memory storage (1TB, 2 TB)
Trigger
Options
Dedicated BNC, via capture port, On-Camera Controls, Image-Based Auto-Trigger,
or via Phantom PCC software
Ethernet
Standard Gb Ethernet and 10Gb Ethernet for faster download speed
Power
Two ports for primary and backup (20-28 VDC) on camera back panel
Video Out
Two HD-SDI ports on camera; Analog video (NTSC or PAL) available on Break-out-Box;
Component viewfinder port
Special
Features
Partition memory into segments and make shorter recordings back-to-back without
missing any action (63 maximum)
Internal mechanical shutter for hands-free and remote CSR
(Current Session Reference)
Advanced ‘On-Camera Controls’ for camera setup, capture, playback, edit,
and save to Phantom CineMag IV
Popular
Accessories
CineMag IV, CineStation IV for CineMag IV, RCU, Break-out-box,
Video monitor for use with on-camera controls
* Measured according to ISO 12232:2006 method
