Chapter 5: Working with Phantom CineMags | 31
10Gb NETWORK SETTINGS
To use the CineStation IV with a 10Gb connection, connect a CAT 6A (or greater) cable from
the 10Gb Ethernet port on the CineStation to an approved 10Gb NIC (Network Interface
Card) in the host computer. Use the following network settings:
10Gb Network IP: 172.16.0.1
Subnet: 255.255.0.0
Once the NIC is installed in the PC, ensure the latest driver is installed from the
manufacturer’s website. Generally, the computer and all devices must be re-booted after
the driver installation.
Ensure that when the Phantom software was installed, the Phantom 10Gb driver was also
installed during that process. If not, it must be installed separately—contact support for
instructions.
For optimum results, ensure there are no bottlenecks in the system—a solid state RAID is
recommended for the fastest save speeds.
