Step 51
Feed the servo extension leads through the
air exit hole and into the radio bay.
Step 52
Hold all leads in place in the duct using
clear tape or masking tape. Do not allow
leads to remain loose in the duct as there is
a risk they will be drawn into the fan.
Step 53
Mix up sufficient rapid epoxy and coat the
bottom of the lower cowl and sparingly
apply epoxy to the fan unit recess to secure
the fan unit to the cowl.
Step 54
Glue the lower cowl in position making sure
it is firmly pressed into its recessed slots.
Ensure that the rear of the cowl is aligned
with the rear of the fuselage.
Step 55
Use small strips of masking tape to
accurately hold the cowl in position as the
epoxy cures.
SEE PAGE 25 - SETTING UP THE ESC
YOU CAN NOW TEST THE ESC AND FAN
UNIT. ENSURE THE FAN ROTATES ANTI-
CLOCKWISE VIEWED FROM THE FRONT.
