Page 23
Step 96
Ensure that the Velcro retaining strap is
orientated as shown as it is glued into the
model with the tray in this position.
Step 97
Place the battery on its tray into the radio
bay.Temporarily fit the canopy and test the
balance point as shown below.
BALANCE POINT (C/G)
The Squall! should balance at a point 60mm back from the leading edge where the wings meet the
fuselage. The Squall! must be correctly balanced before flying. The aircraft should sit level or slightly
nose down when you support it on a balancer or with your finger tips at the balance point. Move the
Li-Po battery on its tray forwards or backwards until the model balances correctly.
60mm
C
G
