SECTION 15: 6CP100/50-10 PARTS LIST
Item
Part Number
Description
Quantity
CONTROL SECTION
CB1,2
1601332
30A, 2P CIRCUIT BREAKER
2
CON1
1151183
MALE CONTACT PINS, GOLD 10-8 AWG
3
CON1
1151178
HIGH CURRENT 3 PIN RECPT.
1
CON2
3150167
MS 22-2 F CONNECTOR ASSEMBLY
1
CON2
1151185
FEMALE CONTACT PINS, GOLD, 10-8 AWG
2
D1-D5
1780025
DIODE 1N4007
5
F1-2
1603599
FUSE, AGC-0.5
2
F1-2
1603920
FUSEHOLDER 3AG
2
K3
1705465
FUR.#42BF35AF 30A/3P
1
LP1,SW10,SW11
1422153
LENS, CLEAR
3
LP1
1423300
LAMP SOCKET
1
LP2
1420162
LED 24VDC RED
1
LP3
1420161
LED 24VDC GREEN
1
LP1,4,SW10
1420163
LED 24VDC WHITE
3
M1,M2
31138800
PCB1388 METER PROTECTION BD
2
M1,M2
1506400
DIGITAL METER, ½ DIGIT LCD
2
M1,M2
1152152
RIBBON CONNECTOR
2
M1,M2
1079909
RIBBON CABLE
6FT
MOV1
1606110
MOVISTOR, V275LA40A
1
PCB1387
31138714
CONTROL/METERING BD
1
R15
1761098
RESISTOR, 10kΩ,2W LINEAR
1
R15-DIAL
1355910
POTENTIOMETER DIAL
1
R15 KNOB
1355101
POTENTIOMETER KNOB
1
R15 -CAP
1355102
PEAKED CAP
1
R15-KNOB
1355905
STATOR BLACK
1
R16A-C
1720201
RESISTOR, 180 Ω, ½ W
3
LP2
1422150
LENS, RED
1
SW10
1860265
SWITCH, LATCH 2 POLE
1
SW11
1860260
SWITCH, LATCH 1 POLE
1
SW2-4
1860120
SWITCH, MOM 1 POLE
3
LP3
1422151
LENS, GREEN
1
LP4
1422148
LENS, BLUE
1
SW5, SW9
1355310
PEAKED CAP
2
SW5
1863042
ROTARY SWITCH, 4P 2-6POS-S.
1
SW7
1866005
ROLLER LIMIT SWITCH
1
SW8
1860900
LATCHING MUSHROOM PB W / KEY
1
SW8
1862905
SIEMENS#3SB3400-OC,NC
1
SW9
1863048
ROTARY SW, 4P, 2-3 POS, SHORTING
1
SX1
1151152
AMP RECPT. 4 FEMALE PIN, SIZE 11
1
SX1
1151174
CONTACT PINS, 24-20 AWG FEMALE
1
T1
1890239
VARIABLE TRANSFORMER, GE #9T92A40
1
T2
1896017
CONTROL POWER TRANSFORMER, 50VA
1
TMR1
9602133
PANEL MOUNT PROGRAMMABLE TIMER
1
TX1
1151158
MS 18-01S F CHASSIS CONNECTOR
1
TX1 CABLE
30160001
METERING INTERCONNECT CABLE
1
