SECTION 1: TECHNICAL SPECIFICATIONS
Input
120 VAC 10 Amps or 220 VAC 5 Amps, 50/60 Hz, single phase (refer to Unit Data Tag)
Output Rating (maximum)
0-100 kilovolts dc
0-5 milliamperes continuous resistive leakage
0-20 milliamperes short term capacitive charging
Internal Discharge Capability 6 kilojoules
Duty Cycle
Continuous – Capacitive Charging
Type of Cooling Natural convection.
Ripple Less than 2 percent RMS at loads of 30 Megohms and higher from 10kV-100KV and
capacitive loads.
Output Negative output, positive ground standard. Positive output available by special order. Filtered voltage
doubler circuit, equivalent to full wave rectification.
Operating Ambient Temperature 0 to 35 degrees Celsius.
Output Termination High voltage cable, shield guarded.
Metering
Output Voltmeter: 3 ½ DIGIT LCD, accuracy .5% of full scale.
Ranges: 0 to 19.99kV, 0-100.0kV
Output Currentmeter: 3 ½ DIGIT LCD, accuracy .5% of full scale.
Ranges of 0 to 19.99a, 199.9A, 1.999mA, 19.99mA
Analog Output 1.5” ANALOG
Charging Indicator: 0-100% of selected range indication.
Size and Weight
22.5" W x 21" D x 16.5" H; 98* lbs. (572 mm W x 533 mm D x 419 mm H; 44.5* kg)
*For 220 V units: add 10 lbs. (4.5 kg)
