Phenix 4100-10 - Parts List

10-2
4100-10 PARTS LIST
ITEM
DESCRIPTION
QTY
PART NO.
CONTROLS
C1, 4
47uF 20V Capacitor
2
1096510
C2
4.7Uf, 35V Capacitor
1
1095010
C3
1 uF 50V Capacitor
2
1094051
C5, 6,10
.033 uF 630v Capacitor
3
1093300
CABLE-GROUND
20 FT. GROUND CABLE ASSY.
1
30080011
CABLE-HV
20 FT. HV CABLE ASSY.
1
30070015
CABLE-RTN
20 FT. RED RETURN CABLE ASSY.
1
30080010
CB1
CIRCUIT BREAKER, 10 AMP, 2-POLE
1
1601314
CORD
INPUT POWER CORD
1
1077167
F1
FUSE, 1 AMP
1
1603601
F1
FUSE HOLDER
1
1603920
J1
BINDING POST, RED
1
1351102
J2
BINDING POST, GREEN
1
1351103
J3
BINDING POST, WHITE
1
1351104
J1-3
SHORTING BAR
1
1351110
K1
RELAY-3 POLE 120 VAC COIL
1
1700610
K101
RELAY – 2 POLE12 VDC COIL
1
1701033
LP1 LENS
CLEAR LENS EAO
1
1422153
LP2 LENS
LENS, RED EAO
1
1422150
LP3 LENS
LENS, GREEN EAO
1
1422151
LP4 LENS
LENS, BLUE EAO
1
1422148
LP1 SOCKET
LAMP SOCKET EAO
1
1423300
LP1-4
LAMP 60V EAO
4
1420150
M1, M2
METER-DIGITAL, 3 ½ DIGIT LCD
2
1506400
M1-CM
METER PROTECTION BOARD ASSY.
1
31126500
M2-VM
METER PROTECTION BOARD ASSY.
1
31126502
M3
METER-ANALOG 1 ½”
1
1501016
MOV1, 2
MOVISTOR, V130LA10A
2
1606100
P1
POWER INPUT RECEPTACLE
1
1153328
PCB Assy.
PCB1257 Rev B METER/OVERLOAD BD
1
31125716
PCB
PCB 1223 (MTG FOR R1-R5)
1
1112232
R1, R2
RESISTOR, 750 OHM, .5W, 1%
4
1711900
R3
RESISTOR, 7.5K OHM, .5W, 1%
2
1712150
R4
RESISTOR, 75K OHM, .5W, 1%
2
1713500
R5
RESISTOR, 750K OHM, .25W, 1%
2
1725050
R6A
RESISTOR, 1.5 MEG OHM, .25W, 1%
1
1735140
R6B
RESISTOR, 39K OHM, .25W, 1%
1
1722618
R7
POTENTIOMETER, LINEAR, 10K, 2W
1
1761098
R7 DIAL
BLACK STATOR
1
1355905
R7 DIAL
0-11 NUMBERED DIAL
1
1355910
R7 KNOB
BLACK KNOB
1
1355101
R7 KNOB
KNOB CAP
1
1355102
SG1, 2
SPARK GAP-90V
2
1605110
SW/LP 2,3,4
SWITCH, PUSHBUTTON, MOMENTARY, 1-POLE
3
1860120
SW5
SWITCH, ROTARY, 3 POLE, 4 POS.-SH.
1
1863042
SW6
SWITCH, ROTARY, 2 POLE, 2-6POS.-SH.
1
1863047
SW5, 6 KNOB
KNOB, ¼”
2
1355310
SW7
SWITCH, ROLLER, CAM, ZERO START
1
1866005
