DCD 4100-10
10-3
4100-10 PARTS LIST
ITEM
DESCRIPTION
QTY
PART NO.
SX1
FEMALE 2 PIN CHASSIS CONN.
1
1151152
SX1
PIN-FEMALE 20GA
2
1151174
SX1 PLUG
MALE 2 PIN CABLE CONN.
1
1151162
SX1 PLUG
CABLE CLAMP
1
1151186
SX1 PLUG
CONTACT SOLDER PINS MALE
2
1151176
THERMAL OVERLOAD
PUSHBUTTON THERMAL CIRCUIT BREAKER-7A
1
1601420
T1
VARIABLE TRANSFORMER
1
1890120
T2 (220V UNITS)
TRANSFORMER, STEP DOWN, 230/115
1
1894433
U101
LM311N
1
1794493
U201, 202
OP400GP OP AMP
1
1794105
Z1-6
1-5KE18A TRANSORB
6
1780065
Z7, 8
1-5KE18C TRANSORB
2
1780069
CASE
1
2100516
HV UNIT
FOR HV UNIT INTERNAL PARTS, REFER TO HV DC TANK SCHEMATIC
