5-2
PARTS LIST (continued)
ITEM DESCRIPTION QTY PART NO.
ASSY. NO. 7309900500, SECTION 03
TRANSFORMER, 120V PRI., 6000V SEC., 1 1896050
130VA, JEFFERSON ELECTRIC #720-33
CASE 1 2100513
SMALL TEST LEAD WIRE (RED) 10’
SMALL TEST LEAD WIRE (BLK) 10’
RG8U, OUTPUT LEAD 10’
D9 DIODE, 40KV, 25MA 1 1782010
EDAL INDUSTRIES B412-40-25
C7,8 CAP., .05UF, 15KV 2 1092565
R35 RES., 47M, ROX1, 6W, 1% 1 1746940
R36 RES., 10K, 10W, 10% 1 1742190
R37 RES., 45M, 6W, 1% 1 1746850
ASSY. NO. 31116901, SECTION 02
PCB1169 PM6 MAIN PCB# 1169 1 1111690
T1 TRANSFORMER ST-4-24, 24V CT, 120V PRI. 1 1894335
K1 RELAY, 12VDC COIL 1 1701035
K2 RELAY, 120VAC COIL, 4PDT 1 1701300
SOCKET 1 1157340
WIRE BALE 1 1703350
Q1 VOLTAGE REG., +12VDC, MC7812CT 1 1794005
Q2 VOLTAGE REG., -12VDC 1 1794006
Q3 SCR, C106B1 1 1803100
D1-6 DIODE, 1N4007 (1000VR, 1A) 6 1780025
U1, 3 OP-AMP CA314OE 2 1790100
U2 OP-AMP COMPARATOR, LM311N 1 1794493
Z 1, Z3 MOVISTOR 35V 2 1606130
Z2 TRANSORB, 10V, IN6273A 2 1780063
C1 CAP. .27UF, 50V 1 1093175
C2 CAP. 10 UF, 20 VDC TANT. 1 1095800
C,3,9,11,12 CAP. .01UF, 1 kV 4 1092050
C4,5 CAP. 470UF, 35VDC 2 1098470
C6,10 CAP. 10UF, 25VDC 2 1095825
