5-1
PARTS LIST
PM6
ITEM DESCRIPTION QTY PART NO.
ASSY. NO. 7109900500, SECTION 01
T2 VARIAC 120V PRI., 0-120V, 1.75A, SEC. .231KVA 1 1890100
F1,F2 FUSE, 2A, GDC 2 1603702
CORCOM INPUT CONN. 1 1152590
INPUT CORD 1 1077170
M1,2 METER, 50UA 2 1501012
SW1,2 SWITCH, 1 POLE 2 1860260
LMP1,2 BULB, 60V EAO 2 1420150
LENS, EAO, GREEN 1 1422151
LABEL, “POWER” 1
LENS, EAO, RED 1 1422150
LABEL, “HV ON” 1
PROTECTIVE GROMMET 1
SW3,SW4 SWITCH, ROTARY, 2 POLE 2 1863047
KNOB FOR ROTARY SWITCH 2 1355310
R23 POT, 10K, SENSITIVITY ADJ 1 1761092
KNOB, FOR ABOVE POT 1355305
ASSY. NO. 7209900500, SECTION 02
PM6 MAIN PCB ASSY PCB 1 31116901
BINDING POST RED (RETURN) 1 1351102
BINDING POST, BLK (GROUND) 1 1351100
BINDING POST, WHITE (GUARD) 1 1351104
SHORTING LINK 1 1351110
BLACK BOOT 1 1353001
RED BOOT 2 1353000
ALLIGATOR CLIPS 3 1353002
½” SPACERS 4 1350104
RUBBER FEET BUMPERS 4 2109500
MOV4-6 130V MOVISTORS 3 1606100
¼” SPACER 1 1350101
3 POS TERM STRIP 1 1156050
