2-3
CONTROLS AND CONNECTIONS
INPUT/OUTPUT CONNECTIONS (continued)
AC Line:
This cord supplies input power to the tester.
Output:
This test lead with clip and insulation boot supplies the testers output to the apparatus
under test.
Fuse:
If this protective fuse opens, AC power to the tester is interrupted.
