PHG VOXIO501 - VOXIO Fingerprint Specifications; General Product Data; Installation Construction Types

Mounting and installation instruction
30.06.16 - 8 - 91130.docx
Rev.:1.40
General Data
Housing
 Housing is made of plastic (ASA)
Temperature
 Storage temperature -25°C bis +60°C
 Operating temperature -10°C bis +50°C
Power supply
 10...30V / DC
(internal polarity reversal protection)
 Maximum power input
without RFID 2,5 W
with RFID 3,5 W
Protection class
 IP 54
Construction
Cable mounted on the wall with cable entry from below
Flush-mounted cable with cable entry through the mounting plate
Installation socket
Mounting plate
Reader
Wall
Holes for mounting
plate
Security screws
Reader
Wall
Holes for mounting
plate
Mounting plate
Security screws
