PHI VILLA AH-FP-30F - Parts List; Installation

Parts list
REF NO
DESCRIPTION
QTY
A
#8 x 1”
8 PCS
B
8 PCS
C
1 PC
D
4 PCS
E
2 PCS
Installation:
Caution: This heater can be installed in two ways, which can be selected according to
your preference.
Type 1. Built-in Wall
Clearance: Please allow a minimum of 0.5” spacing from the rear of the unit to a wall.
Wall Opening Dimensions:
Note: Before installing the heater, please confirm the opening size of the wall.
