Device Specications
Characteristic Value
Position Resolution 1/16
th
step (40-bit signed)
Maximum Position Limit 2
39
- 1 1/16
th
steps (40-bit signed)
Minimum Position Limit -(2
39
-1) 1/16
th
steps
Velocity Resolution 8 1/16
th
steps/second (12-bit)
Velocity Limit 32,768 1/16
th
steps/second
Acceleration Resolution 4,000 1/16
th
steps/second
2
(8-bit)
Acceleration Minimum 4,000 1/16
th
steps/second
2
Acceleration Limit 1,020,000 1/16
th
steps/second
2
Maximum Top End Torque 1,000 oz/in @ 2.5 amps
Digital Input Update Rate ~125 samples/second
Digital Input Pull-Up Resistance 15K ohms
Digital Input Recommended Wire Size 16 - 26 AWG
Minimum Power Supply Voltage 9V
Maximum Power Supply Voltage 30V
Max Current Per Coil 2.5A
USB-PowerCurrentSpecication 100mA
Product History
Date Board Revision Device Version Comment
January 2009 0 Product Release
Support
Call the support desk at 1.403.282.7335 9:00 AM to 5:00 PM Mountain Time (US & Canada) - GMT-07:00
or
E-mail us at: support@phidgets.com
