Philco PSL 40F CUBE - Page 14

Copyright © 2020, Fast ČR, a. s. Revision 04/2022
EN - 12
5. Unscrew and remove the bottom hinge pin, turn the bracket over and replace it.

6. Retthebracketttingthebottomhingepin.Replaceboth
adjustable feet.
7. Place the door back on. Ensure the door is aligned horizontally
andverticallysothatthesealsareclosedonallsidesbeforenally
tightening the top hinge.
8. Insert the hinge bracket and screw it to the top of the unit.
9. Use a spanner to tighten it if necessary.
10. Put the hinge cover and the screw cover back.
11. Detach the Fridge and the Freezer door gaskets and then attach them
after rotating.
