PART 3: REVERSE DOOR
Tool required: Philips screwdriver, Flat bladed screwdriver, Hexagonal spanner.
• Ensuretheunitisunpluggedandempty.
• Totakethedooro,itisnecessarytotilttheunitbackwards.Youshouldresttheunitonsomethingsolid
so that it will not slip during the door reversing process.
• Allpartsremovedmustbesavedtodothereinstallationofthedoor.
• Donotlaytheunitatasthismaydamagethecoolantsystem.
• It’sbetterthat2peoplehandletheunitduringassembly.
1. Remove the top right hinge cover.
2. Undo the screws. Then remove the hinge bracket.
3. Remove the top left screw cover.
4. Move the core cover from left side to right side. And then lift the upper
door and place it on a padded surface to prevent it from scratching.
unscrew
