NOTES:
C…..±0.25% D…..±0.5% F…..±1%
G…..±2% J…..±5% K…..±10%
M…..±20% N…..±30% Z…..+80/-20%
ELECTRICAL PARTS LIST
Pos.
h
12 NC Description
MMA CBA 111111111
Consists of the following
MAIN CBA 111111111
JUNCTION A CBA 111111111
JUNCTION B CBA 111111111
JUNCTION C CBA 111111111
SENSOR CBA 111111111
POWER CBA 111111111
CRT CBA 111111111
MAIN CBA
CAPACITORS
C001 CHIP CERAMIC CAP.(MELF) F Z 0.01UF/16V 111111111
C002 ELECTROLYTIC CAP. 47UF/25V M 111111111
C005 CHIP CERAMIC CAP.(MELF) F Z 0.01UF/16V 1 1 1
C006 ELECTROLYTIC CAP. 1UF/50V M 111111111
C008 ELECTROLYTIC CAP. 1UF/50V M 111111111
C009 PCB JUMPER D0.6-P5.0 111111111
C014 PCB JUMPER D0.6-P5.0 1 1 1
C101 FILM CAP.(P) 0.056UF/50V J 1 1
C102 ELECTROLYTIC CAP. 4.7UF/50V M H7 1 1
C103 CHIP CERAMIC CAP.(MELF) F Z 0.01UF/16V 1 1
C104 ELECTROLYTIC CAP. 47UF/6.3V M H7 1 1
C105 ELECTROLYTIC CAP. 1UF/50V M H7 1 1
C106 ELECTROLYTIC CAP. 1UF/50V M H7 1 1
C151 ELECTROLYTIC CAP. 330UF/16V M 111111111
C152 CERAMIC CAP.(AX) X M 2200PF/16V 111111111
C154 ELECTROLYTIC CAP. 470UF/16V M 111111111
C155 ELECTROLYTIC CAP. 0.22UF/50V M H7 111111111
C156 CHIP CERAMIC CAP.(1608) B K 4700PF/50V 111111111
C157 ELECTROLYTIC CAP. 10UF/25V M H7 111111111
C160 CHIP CERAMIC CAP.(1608) CH J 270PF/50V 111111111
C203 CHIP CERAMIC CAP.(MELF) F Z 0.01UF/16V 111111111
C205 CHIP CERAMIC CAP.(MELF) F Z 0.01UF/16V 111111111
C207 ELECTROLYTIC CAP. 1UF/50V M H7 111111111
C208 CHIP CERAMIC CAP.(MELF) F Z 0.01UF/16V 111111111
C209 CHIP CERAMIC CAP.(1608) CH J 22PF/50V 111111111
C210 CHIP CERAMIC CAP.(1608) CH J 22PF/50V 111111111
C211 ELECTROLYTIC CAP. 47UF/6.3V M H7 111111111
C212 CHIP CERAMIC CAP.(MELF) F Z 0.01UF/16V 111111111
C213 ELECTROLYTIC CAP. 47UF/6.3V M H7 111111111
C214 ELECTROLYTIC CAP. 330UF/6.3V M 111111111
C217 CHIP CERAMIC CAP. CH D 10PF/50V 111111111
PRODUCT SAFETY NOTE: Products marked with a h
have special characteristics important to safety.
Before replacing any of these components, read carefully
the product safety notice in this service manual.
Don’t degrade the safety of the product through improper servicing.
14PV385/39 14PV135/07 14PV235/01 14PV235/58 14PV385/07 14PV135/01 14PV135/58 14PV235/07 14PV385/01
1-14-17
