1-5-6 T6450DC
CABINET DISASSEMBLY INSTRUCTIONS
[ 14PV135/ (01, 07, 58), 14PV235/ (01, 07, 58), 14PV385/ (01, 07, 39) ]
Comparison Chart of Models and Marks
1. Disassembly Flowchart
This flowchart indicates the disassembly steps for the
cabinet parts, and the CBA in order to gain access to
item(s) to be serviced. When reassembling, follow the
steps in reverse order. Bend, route and dress the
cables as they were.
Caution !!
When removing the CRT, be sure to discharge the
Anode Lead of the CRT with the CRT Ground Wire
before removing the Anode Cap.
2. Disassembly Method
(1): Order of steps in Procedure. When reassembling,
follow the steps in reverse order.These numbers
are also used as the identification (location) No. of
parts in Figures.
(2): Parts to be removed or installed.
(3): Fig. No. showing Procedure of Part Location.
(4): Identification of part to be removed, unhooked,
unlocked, released, unplugged, unclamped, or
desoldered.
S=Screw, P=Spring, L=Locking Tab, CN=Connec-
tor, *=Unhook, Unlock, Release, Unplug, or Desol-
der
2(S-2) = two Screw (S-2)
(5): Refer to the following "Reference Notes in the
Ta bl e. "
Model Mark
14PV135/07 E
14PV235/07 F
14PV385/07 G
14PV135/01 H
14PV235/01 I
14PV385/01 J
14PV135/58 K
14PV235/58 L
14PV385/39 M
[1] Rear Cabinet
[2] Power Unit and Tray Chassis Unit
[3] Power Unit[5] H.V./Power
Supply CBA
[4] Tray Chassis Unit
[6] Top Cover
[7] Bottom Plate
[8] Deck Unit
[9] Text CBA [ F,G,I,J,L,M ]
[10] Main CBA
[11] CRT
ID/
LOC.
No.
PART
REMOVAL
Fig.
No.
REMOVE/
*UNHOOK/
UNLOCK/RELEASE/
UNPLUG/DESOL-
DER
Note
[1]
Rear
Cabinet
1,2,5
4(S-1), 2(S-2),
*CN804
1
[2]
Power Unit
and Tray
Chassis
Unit
3,4,5
Anode Cap, *CN501,
*CN551, *CN601,
CRT CBA
2
[3] Power Unit 3,5
*CN502, *CN552,
*CN602
3
[4]
Tray
Chassis
Unit
3 ---------- -
[5]
H.V./Power
Supply
CBA
36(S-3) 4
[6] Top Cover 3 5(S-4), CL604 5
[7]
Bottom
Plate
3(S-5) 6
[8] Deck Unit 3, 5
7(S-6), (S-7), (S-8),
Desolder *(CN201,
CL401, CL402,
CL403)
7
[9]
Tex t C B A --
[ F,G,I,J,L,
M ]
3, 5
(S-9), *CN751,
*CN752
8
[10] Main CBA 3 4(S-10) 9
[11] CRT 4 4(S-11) 10
↓
(1)
↓
(2)
↓
(3)
↓
(4)
↓
(5)
To Next Page
