This monitor is ENERGY STAR
®
compliant. As an ENERGY STAR
®
Partner, PHILIPS has
determined that this product meets the
ENERGY STAR
®
guidelines for energy efficiency.
RETURN TO TOP OF THE PAGE
Physical Specifications
• Dimension (WxHxD) 387 x 375 x 183 mm (incl. Pedestal)
• Weight 5.0 Kg
• Power supply 100 — 240 VAC, 50/60 Hz
• Power consumption 27 W
• Temperature (operating) 0° C to 35° C
• Relative humidity 20% to 80%
• System MTBF 50K hrs (excluding LCD panel, CCFL)
* These information are subject to change without notice.
RETURN TO TOP OF THE PAGE
Pin Assignment
The 15-pin D-sub connector (male) of the signal cable:
Pin
No.
Assignment
Pin
No.
Assignment
1 Red video input 9 +5V power
2 Green video input 10 Logic ground
